منتوج وصف
This ESD anti-fatigue mat is designed to provide both reliable static protection and superior ergonomic comfort. Positioned between our durable and economical series, it combines enhanced performance with great value.
ESD Anti-Fatigue Mat (Dual-Layer PVC Type)
| Item | Description |
|---|---|
| Product Positioning | Mid-range model – balancing durability and cost-effectiveness |
| Structure | Dual-layer PVC design: top wear-resistant surface + bottom foam layer |
| Material | PVC (both layers are anti-static) |
| Surface Resistivity | 10⁵ – 10⁸ Ω/sq (conductive & static dissipative) |
| Sheet Size | 60x90cm or other customized size |
| Roll Size | 60CM 90CM 120CM, length could be customized |
| Foam Layer Resistivity | 10⁹ – 10¹⁰ Ω/sq |
Key Features:
-
Dual-Layer PVC Design: The upper layer is a highly wear-resistant surface, while the lower foam layer provides excellent cushioning. Both layers are made of conductive PVC material, offering inherent static dissipation.
-
Patented Open-Cell Structure: Effectively disperses pressure, promotes leg circulation, and reduces fatigue from prolonged standing.
-
Conductive and Static-Dissipative Properties: Surface resistivity ranges from 10⁵ to 10⁸ Ω/sq, and foam layer resistivity ranges from 10⁹ to 10¹⁰ Ω/sq, ensuring safe ESD protection in electronic work areas.
-
Slip-Resistant Beveled Edges: Ensures stable floor contact and reduces the risk of tripping or slipping.
-
Long-Lasting Performance: The ultra-durable wear layer extends the service life even under heavy foot traffic.
-
Applications:
Ideal for use in ESD-sensitive environments such as electronic assembly lines, laboratories, testing areas, and cleanrooms.
